1304 301 410 Speedometer Cover
ZF

1304 301 410 Speedometer Cover (ZF 1304301410)

Brand : ZF
Price : €0,00
Stock Amount : 2
Add to Favorites
Add to My Wish List
Compare
Notify me when it is in stock

ADET

Artır Azalt
Write a comment
Questions (0) and Answers (0)
OEM INFO
OEM OEM CODE
ASHOK-LEYLAND - CUMMINS F5J00542
DAF TRUCKS 1829227
IVECO 42562358
MAN NUTZFAHRZEUGE AG 81.32810-0080
RENAULT TRUCKS 7421415494
VOLVO 21415494
NUMBER INFORMATION
NEW NUMBER OLD NUMBER
1304301351
1304301409
MODIFICATION INFORMATION
MODIFICATION NUMBER PRIORITY REASON FOR MOD. INFO ABOUT CHANGE REASON FOR MOD. ACTION OF MOD. START-UP EXPIRY DATE
Z00001502411 use up old parts completely Rationalization Cost Reduction idea to delete adjustment shim WTB 0769.140.190 between tachometer cover 1304.301.409 and output ball bearing for current Ecomid and E21 for version with standard mechanical and ele electronical version: old: 1304.301.409 new: tachometer cover without adjustment shim 1304.301.410 (for info CPK dimension 7 + 0.05 = 5.91 and for housing III = 2.01 mechnaical version: old: 1304.3 2008-11-12 2008-11-12
Z00019154010 immediately Customer Tightning torque for locking screw 0636.100.791(with sealing ring 0634.801.062) = 35 Nm in all 1324 specifications Tightning torque decreased to 30 Nm 2012-11-08 2012-11-08
Z00021958210 immediately Customer Optimisation radial shaft seal on output flanges Ecomid (common with Traxon, AStronic, ASTronicmid, Ecosplit) Replace following part numbers as set for part lists 1324: 0734.319.459 by new radial shaft seal with 3 lips 0734.300.421; 0000.702.532 by 0000.702.591, installation dimension 59,5 ±0,2 mm stays same 2013-09-26 2013-09-26
