0501 209 188 Ball Caster
ZF

0501 209 188 Ball Caster (ZF 0501209188)

Brand : ZF
Price : €0,00
Stock Amount : 43
Add to Favorites
Add to My Wish List
Compare
Notify me when it is in stock

ADET

Artır Azalt
Write a comment
Questions (0) and Answers (0)
TECHNICAL INFORMATION
KPL.
OEM INFO
OEM OEM CODE
ASHOK-LEYLAND - CUMMINS F0262510
Astra Veicoli Industriali 117682
DAF TRUCKS NV 1295215
RENAULT TRUCKS 5001842967
DAIMLER AG A0002655874
DAIMLER BUSES 8.913.003.048
FAUN ZF150076
FORCE MOTORS LTD 64.91301-6001
Hyundai Motor Company QZ0501209188
IVECO 42531515
MAN NUTZFAHRZEUGE AG 81.95801-0165
NEOPLAN BUS GMBH 0521.295.50
S.N.V.I.-C.V.I. 0001132016
TATA MOTORS LTD 286526719906
VAN HOOL 9209
VOLVO 3099390
MODIFICATION INFORMATION
MODIFICATION NUMBER PRIORITY REASON FOR MOD. INFO ABOUT CHANGE REASON FOR MOD. ACTION OF MOD. START-UP EXPIRY DATE
Z00009642210 immediately Customer new application of Dongfeng's Eco.4+ NH/1B + IT3 creat parts list according to attached questionaires 2010-10-07 2010-10-07
Z00012350610 immediately Customer Customer S.N.V.I parts list 1324 003 155 The installation check has been carried out. Several changes has to be done. parts list 1324 003 155 - adjust spring tuning - adjust use case as discribed in the attachment and please see also the attached installation report. 2011-04-20 2011-04-20
Z00021240310 immediately Customer Hyundai Eco4 16S1830/1 TO bitte Änderung nach Inbetriebnahme kw13/13 durchführen: SL: 1355.002.057/070/071 SL: 1355.031.058 SL: 1355.051.129/133/144/145 - Rastenhebelanordnung "A" (bisher "C") - RG Druckfeder 0732.040.985 2013-04-04 2013-04-04
Z00026363710 immediately Customer China localized shift heads with servo add localized parts as WTB in ths CGS shift housing that assembled for C-Line and 9S T/Ms at ZFDH, detail see attachment 2014-06-30 2014-06-30
Z00028632910 immediately Customer Nach IBN sind im Projekt WS23neu am Ecosplit 1341.031.064 ein paar Änderungen notwendig Bitte folgende Änderungen lt. IBN-Bericht durchführen: 1.Speed sensor and connection cable 6029.199.052 have to be removed from part list, 2. The cables 6029.005.023 for R, N and GP should be changed 2015-01-22 2015-01-22
Z00032363310 immediately Customer Accomplished installation check on KAMAZ vehicle 7330 (10x4). Adaptations of p/l 1341.031.057 necessary. Please adapt the part list number 1341.031.057 as following: - change shift detent spring to 1324.207.006 (123N) - change reverse gear detent spring to 0732.040.985/0732.040.984 - status to K40 More 2015-08-25 2015-08-25
Z00037902710 immediately Customer Projekt:TD03 lt. IBN-Bericht von Mehmet Tilki sollten in der SL 4283.031.001 Änderungen fuer die Serie vorgenommen werden. Bitte folgende Änderungen vornehmen: Höckerfeder: ALT:0732.041.500 NEU:0732.041.612 R-Gangfeder: ALT:0732.041.612 NEU:0732.042.207 Wählhebel: ALT:1324 2016-11-09 2016-11-09
Z00039602010 immediately Customer Ecosplit - The plug to close the air-connection GV-valve is documented in Eco3 in the conservation group; in Eco4 in the shift housing. Please add the missing plug into the affected Eco4 parts list and delete the plug in the Eco3 parts list --> see attachment. 2017-02-27 2017-02-27
Z00047156010 immediately Customer Customer - Ashok Leyland Change of Reverse detent spring and Range group change after installation check ZF Part Number – 1355.033.001 (8S 1835 TO) AL Part Number - B5P54701 Project – HMV 12X12 Changes: Reverse spring Old: 0732.040.985 New: 0732.040.986 + 0732.040.984 Range Group spring: Old: 0732.040 2018-11-05 2018-11-05
