1304 301 410 Takometre Kapağı
1304 301 410 Takometre Kapağı
ZF

1304 301 410 Takometre Kapağı (ZF 1304301410)

Marka : ZF
Fiyat : €0,00
Stok Miktarı : 2
Favorilere Ekle
İstek Listeme Ekle
Karşılaştır
Gelince Haber Ver

ADET

Artır Azalt
Yorum Yaz
Sorular (0) ve Cevaplar (0)
OEM BİLGİLERİ
OEM OEM KODU
ASHOK-LEYLAND - CUMMINS F5J00542
DAF TRUCKS 1829227
IVECO 42562358
MAN NUTZFAHRZEUGE AG 81.32810-0080
RENAULT TRUCKS 7421415494
VOLVO 21415494
NUMARA BİLGİLERİ
YENİ NUMARA ESKİ NUMARA
1304301351
1304301409
MODİFİKASYON BİLGİLERİ
MODİFİKASYON NO ÖNCELİK NEDENİ DEĞİŞİKLİK BİLGİSİ NEDENİ EYLEM BAŞLANGIÇ SON TARİH
Z00001502411 use up old parts completely Rationalization Cost Reduction idea to delete adjustment shim WTB 0769.140.190 between tachometer cover 1304.301.409 and output ball bearing for current Ecomid and E21 for version with standard mechanical and ele electronical version: old: 1304.301.409 new: tachometer cover without adjustment shim 1304.301.410 (for info CPK dimension 7 + 0.05 = 5.91 and for housing III = 2.01 mechnaical version: old: 1304.3 2008-11-12 2008-11-12
Z00019154010 immediately Customer Tightning torque for locking screw 0636.100.791(with sealing ring 0634.801.062) = 35 Nm in all 1324 specifications Tightning torque decreased to 30 Nm 2012-11-08 2012-11-08
Z00021958210 immediately Customer Optimisation radial shaft seal on output flanges Ecomid (common with Traxon, AStronic, ASTronicmid, Ecosplit) Replace following part numbers as set for part lists 1324: 0734.319.459 by new radial shaft seal with 3 lips 0734.300.421; 0000.702.532 by 0000.702.591, installation dimension 59,5 ±0,2 mm stays same 2013-09-26 2013-09-26
